PAN Junfeng，LU Chuang，MA Xiaohui，et al. System and application of regional fracking of coal seam roof on and under the ground to prevent rockburst[J]. Coal Science and Technology，2023，51（2）：106−115. DOI: 10.13199/j.cnki.cst.2022-0903
|
To solve the problems of small local relief range, low continuity and high operational risk of rockburst, regional hydro-fracking and burst prevention system and engineering application research were carried out within thick and hard roof of a coal seam by well over thousand meters on and under the ground. The results show that, according to the loading conditions, the roof dominated rockburst can be divided into three types: superposed dynamic and static loading type, high static loading type and high static unloading type; The thick and hard roof is the main source of regional static and dynamic loading for rock burst initiation of mining surrounding rock. With the thick and hard roof as the target, which provides the source of dynamic and static load for rock burst initiation, a segmented fracturing pressure relief system for the roof with 1000 meter horizontal holes on and under the ground was established and fracking was carried out in this area. By destroying the integrity of the overlying roof in the burst prone area in advance on and under the ground, the load is transferred to the more intact roof area, so as to provide a low stress operational environment for underground excavation and extraction, and also make the rock burst initiation conditions inapplicable. The fracking and burst control tests on the roof area using the horizontal well drilled on the ground before the extraction of the panel, and underground drilling from the entries during the extraction were carried out respectively. Remarkable results have been achieved in practice, forming a new disaster prevention and control mode of “fracking before construction” for burst prone coal mines under construction, and “fracking before tunneling, fracturing before mining” for the producing coal mines.
| [1] |
应急管理部2022年3月例行新闻发布会[R]. 中华人民共和国应急管理部, 2022.
|
| [2] |
齐庆新,李一哲,赵善坤,等. 我国煤矿冲击地压发展70年: 理论与技术体系的建立与思考[J]. 煤炭科学技术,2019,47(9):1−40.
QI Qingxin,LI Yizhe,ZHAO Shankun,et al. 70 years of development of coal mine rockburst: establishment and thinking of theory and technology system[J]. Coal Science and Technology,2019,47(9):1−40.
|
| [3] |
潘俊锋,毛德兵,蓝 航,等. 我国煤矿冲击地压防治技术研究现状及展望[J]. 煤炭科学技术,2013,41(6):21−25, 41.
PAN Junfeng,MAO Debing,LAN Hang,et al. Research status and Prospect of coal mine rockburst control technology in China[J]. Coal Science and Technology,2013,41(6):21−25, 41.
|
| [4] |
姜耀东,赵毅鑫. 我国煤矿冲击地压的研究现状: 机制、预警与控制[J]. 岩石力学与工程学报,2015,34(11):2188−2204.
JIANG Yaodong,ZHAO Yixin. Research status of rockburst in China: mechanism, early warning and control[J]. Journal of Rock Mechanics and Engineering,2015,34(11):2188−2204.
|
| [5] |
宋振骐,汤建泉,刘建康. 我国冲击地压研究现状及发展方向[J]. 煤炭与化工,2015,38(5):1−4.
SONG Zhenqi,TANG Jianquan,LIU Jiankang. Research status and development direction of rockburst in China[J]. Coal and Chemical Industry,2015,38(5):1−4.
|
| [6] |
姜耀东,潘一山,姜福兴,等. 我国煤炭开采中的冲击地压机理和防治[J]. 煤炭学报,2014,39(2):205−213. doi: 10.13225/j.cnki.jccs.2013.0024
JIANG Yaodong,PAN Yishan,JIANG Fuxing,et al. Mechanism and prevention of rockburst in coal mining in China[J]. Journal of China Coal Society,2014,39(2):205−213. doi: 10.13225/j.cnki.jccs.2013.0024
|
| [7] |
王志强,乔建永,武 超,等. 基于负煤柱巷道布置的煤矿冲击地压防治技术研究[J]. 煤炭科学技术,2019,47(1):69−78. doi: 10.13199/j.cnki.cst.2019.01.009
WANG Zhiqiang,QIAO Jianyong,WU Chao,et al. Study on prevention and control technology of coal mine rock burst based on negative coal pillar roadway layout[J]. Coal Science and Technology,2019,47(1):69−78. doi: 10.13199/j.cnki.cst.2019.01.009
|
| [8] |
潘俊锋,齐庆新,刘少虹,等. 我国煤炭深部开采冲击地压特征、类型及分源防控技术[J]. 煤炭学报,2020,45(1):111−121. doi: 10.13225/j.cnki.jccs.YG19.1638
PAN Junfeng,QI Qingxin,LIU Shaohong,et al. Characteristics, types and prevention and control technologies of rock burst caused by deep coal mining in China[J]. Journal of China Coal Society,2020,45(1):111−121. doi: 10.13225/j.cnki.jccs.YG19.1638
|
| [9] |
谭云亮,郭伟耀,赵同彬,等. 深部煤巷帮部失稳诱冲机理及“卸-固”协同控制研究[J]. 煤炭学报,2020,45(1):66−81.
TAN Yunliang,GUO Weiyao,ZHAO Tongbin,et al. Study on the induced scour mechanism and "unloading solid" coordinated control of the deep coal roadway wall[J]. Journal of China Coal Society,2020,45(1):66−81.
|
| [10] |
齐庆新,潘一山,舒龙勇,等. 煤矿深部开采煤岩动力灾害多尺度分源防控理论与技术架构[J]. 煤炭学报,2018,43(7):1801−1810.
QI Qingxin,PAN Yishan,SHU Longyong,et al. Theoretical and technical framework of multi-scale and multi-source prevention and control of coal and rock dynamic disasters in deep mining[J]. Journal of China Coal Society,2018,43(7):1801−1810.
|
| [11] |
谭云亮,郭伟耀,辛恒奇,等. 煤矿深部开采冲击地压监测解危关键技术研究[J]. 煤炭学报,2019,44(1):160−172.
TAN Yunliang,GUO Weiyao,XIN Hengqi,et al. Key technology of rock burst monitoring and control in deep coal mining[J]. Journal of China Coal Society,2019,44(1):160−172.
|
| [12] |
潘俊锋,刘少虹,秦子晗,等. 深部盘区巷道群集中静载荷型冲击地压机理与防治[J]. 煤炭学报,2018,43(10):2679−2686. doi: 10.13225/j.cnki.jccs.2018.0016
PAN Junfeng,LIU Shaohong,QIN Zihan,et al. Mechanism and prevention of concentrated static load type rock burst ofroadway group in deep mining area[J]. Journal of China Coal Society,2018,43(10):2679−2686. doi: 10.13225/j.cnki.jccs.2018.0016
|
| [13] |
高明仕,赵一超,高晓君,等. 近直立特厚煤层组中间岩板诱发冲击矿压机理及其防治[J]. 采矿与安全工程学报,2019,36(2):298−305.
GAO Mingshi,ZHAO Yichao,GAO Xiaojun,et al. Mechanism and prevention of rock burst induced by intermediate rock plate in near vertical ultra thick coal seam group[J]. Journal of Mining and Safety Engineering,2019,36(2):298−305.
|
| [14] |
姜福兴,刘 懿,张益超,等. 采场覆岩的“载荷三带”结构模型及其在防冲领域的应用[J]. 岩石力学与工程学报,2016,35(12):2398−2408.
JIANG Fuxing,LIU Yi,ZHANG Yichao,et al. A three-zone structure loading model of overlying strata and itsapplication on rockburst prevention[J]. Chinese Journal of Rock Mechanics and Engineering,2016,35(12):2398−2408.
|
| [15] |
姜福兴,张兴民,杨淑华,等. 长壁采场覆岩空间结构探讨[J]. 岩石力学与工程学报,2006,25(5):979−984. doi: 10.3321/j.issn:1000-6915.2006.05.018
JIANG Fuxing,ZHANG Xingmin,YANG Shuhua,et al. Discussion on overlying strata spatial structures of longwall in coal mine[J]. Chinese Journal of Rock Mechanics and Engineering,2006,25(5):979−984. doi: 10.3321/j.issn:1000-6915.2006.05.018
|
| [16] |
窦林名,贺 虎. 煤矿覆岩空间结构OX-F-T演化规律研究[J]. 岩石力学与工程学报,2012,31(3):453−460. doi: 10.3969/j.issn.1000-6915.2012.03.003
DOU Linming,HE Hu. Study of OX-F-T spatial structure evolution of overlying strata in coal mines[J]. Chinese Journal of Rock Mechanics and Engineering,2012,31(3):453−460. doi: 10.3969/j.issn.1000-6915.2012.03.003
|
| [17] |
徐学锋,窦林名,曹安业,等. 覆岩结构对冲击矿压的影响及其微震监测[J]. 采矿与安全工程学报,2011,28(1):11−15. doi: 10.3969/j.issn.1673-3363.2011.01.003
XU Xuefeng,DOU Linming,CAO Anye,et al. Effect of overlying strata structures on rock burst and micro-seismic monitoring analysis[J]. Journal of Mining & Safety Engineering,2011,28(1):11−15. doi: 10.3969/j.issn.1673-3363.2011.01.003
|
| [18] |
潘立友,孙刘伟,范宗乾. 深部矿井构造区厚煤层冲击地压机理与应用[J]. 煤炭科学技术,2013,41(9):126−128, 137. doi: 10.13199/j.cnki.cst.2013.09.029
PAN Liyou,SUN Liuwei,FAN Zongqian. Mine pressure bump mechanism of thick seam in deep mine structure zone and application[J]. Coal Science and Technology,2013,41(9):126−128, 137. doi: 10.13199/j.cnki.cst.2013.09.029
|
| [19] |
罗 浩,李忠华,王爱文,等. 深部开采临近断层应力场演化规律研究[J]. 煤炭学报,2014,39(2):322−327. doi: 10.13225/j.cnki.jccs.2013.2006
LUO Hao,LI Zhonghua,WANG Aiwen,et al. Study on the evolution law of stress field when approaching fault in deep mining[J]. Journal of China Coal Society,2014,39(2):322−327. doi: 10.13225/j.cnki.jccs.2013.2006
|
| [20] |
王爱文,潘一山,李忠华,等. 断层作用下深部开采诱发冲击地压相似试验研究[J]. 岩土力学,2014,35(9):2486−2492.
WANG Aiwen,PAN Yishan,LI Zhonghua,et al. Similar experimental study of rockburst induced bymining deep coal seam under fault action[J]. Rock and Soil Mechanics,2014,35(9):2486−2492.
|
| [21] |
裴广文,纪洪广. 深部开采过程中构造型冲击地压的能量级别预测[J]. 煤炭科学技术,2002,30(7):48−51. doi: 10.3969/j.issn.0253-2336.2002.07.016
PEI Guangwen,JI Hongguang. Prediction on energy classification of structure type pressure bump during deep mining operation[J]. Coal Science and Technology,2002,30(7):48−51. doi: 10.3969/j.issn.0253-2336.2002.07.016
|
| [22] |
吕进国,王 涛,丁维波,等. 深部开采逆断层对冲击地压的诱导机制[J]. 煤炭学报,2018,43(2):405−416. doi: 10.13225/j.cnki.jccs.2017.1211
LYU Jinguo,WANG Tao,DING Weibo,et al. Induction mechanisms of coal bumps caused by thrust faults during deep mining[J]. Journal of China Coal Society,2018,43(2):405−416. doi: 10.13225/j.cnki.jccs.2017.1211
|
| [23] |
潘俊锋. 煤矿冲击地压启动理论及其成套技术体系研究[J]. 煤炭学报,2019,44(1):173−182. doi: 10.13225/j.cnki.jccs.2018.1156
PAN Junfeng. Theory of rock burst start-up and its complete technology system[J]. Journal of China Coal Society,2019,44(1):173−182. doi: 10.13225/j.cnki.jccs.2018.1156
|
| [24] |
PAN Junfeng,DU Taotao,GAO Jiaming,et al. Mechanism and prevention of rockburst in deep multipillar gob-side entry[J]. Lithosphere,2022(4):1509697. doi: 10.2113/2022/1509697
|
| 1. |
何柳春. 地下车库顶板防排水方案设计及应用论证. 中国住宅设施. 2025(01): 28-30 .
| |
| 2. |
谭毅，王宇，何满潮，李辉，郭文兵，李林猫，刘伟东，张少普. 深埋特厚煤层坚硬顶板多维分段水力压裂控冲减损技术. 煤炭学报. 2025(02): 794-809 .
| |
| 3. |
顾倩悦，曹安业，杨耀，边戈，赵卫卫，高红兵，李庚，刘彦强. 高位长钻孔爆破防治冲击地压技术研究及应用. 采矿与岩层控制工程学报. 2025(02): 125-135 .
| |
| 4. |
潘俊锋，邬建宏，贺海鸿，高家明，马小辉，杜涛涛，吕大钊. 煤层顶板“人造解放层”采动响应规律相似模拟研究. 采矿与岩层控制工程学报. 2025(02): 5-21 .
| |
| 5. |
赵凯凯，朱凯雄，冯彦军，孙晓冬，郑仰发，王鹏，王宇. 煤矿井下水平钻孔压裂裂缝起裂特征研究. 煤炭工程. 2025(03): 134-142 .
| |
| 6. |
杨欢，王泽阳，郑凯歌，李彬刚，李延军，杨森，王豪杰，戴楠，王林涛. 双厚组合坚硬顶板定向长钻水力压裂评价体系研究. 中国矿业. 2024(01): 163-169 .
| |
| 7. |
蔡谊军，李鹏飞，计平. 下沟煤矿煤柱回收工作面冲击地压防治技术. 陕西煤炭. 2024(01): 112-115 .
| |
| 8. |
潘俊锋，刘少虹，马文涛，夏永学，王书文，冯美华. 陕西煤矿冲击地压发生规律与分类防治. 煤炭科学技术. 2024(01): 95-105 .
本站查看
| |
| 9. |
王国法，潘一山，赵善坤，庞义辉，何勇华，魏文艳. 冲击地压煤层如何实现安全高效智能开采. 煤炭科学技术. 2024(01): 1-14 .
本站查看
| |
| 10. |
郑纪峰，李啸天. 厚硬顶板隅角悬顶分段多次水力压裂技术研究. 煤炭技术. 2024(03): 21-25 .
| |
| 11. |
邓辉，王铁宏，马文涛. 中央大巷采空区影响区域冲击危险源探测技术. 陕西煤炭. 2024(05): 80-84 .
| |
| 12. |
郝宪杰，孙希奎，唐忠义，付鹏鑫，罗江昊，沈灵杰，唐宽旭. 覆岩高位整层爆破卸压“人造预裂层”源头防治冲击地压技术体系及应用. 煤炭学报. 2024(03): 1318-1331 .
| |
| 13. |
王飞，马文涛，亢晓涛，焦伟，尚楠，马江鹏，马宏源. 厚硬顶板地面水力致裂防治冲击地压技术研究. 煤炭工程. 2024(08): 59-64 .
| |
| 14. |
徐刚，张震，张春会，范志忠，卢振龙，黄志增，陆闯，薛吉胜，王传朋，陈法兵，李岩，刘前进，李正杰，孙晓东，蔺星宇，马镕山. 我国煤矿开采工作面顶板灾害及防治技术研究现状. 采矿与岩层控制工程学报. 2024(05): 16-41 .
| |
| 15. |
王永，张建，朱宁强，李学龙. 深孔爆破断顶技术在深井冲击地压防治工作的研究与应用. 矿业安全与环保. 2024(05): 52-60 .
| |
| 16. |
邬建宏，潘俊锋，冯美华，陆闯，高家明，闫耀东，马宏源. 顶板不同区域压裂程度覆岩采动响应特征. 煤炭学报. 2024(11): 4351-4364 .
| |
| 17. |
齐庆新，马世志，孙希奎，赵善坤，李云鹏，李海涛，于斌，潘鹏志，王守光，李宏，李一哲，王旭东，张修峰，王学滨，李宏艳，陆菜平，王书文，韩军，乔文俊，张宁博. 煤矿冲击地压源头防治理论与技术架构. 煤炭学报. 2023(05): 1861-1874 .
| |
| 18. |
李红平，杜涛涛，孙秉成，杨伟，常博，赵志鹏，贾兵兵，刘江. 坚硬顶板磨砂射流轴向切顶初次放顶应用研究. 煤炭工程. 2023(12): 102-107 .
|
