| Citation: |
XU Huaqiao，RONG Junfeng，MA Haochen. Analysis of the influence of bitumen filling on the mechanical characteristics of collapsible wall joints[J]. Coal Science and Technology，2025，53（6）：445−455. DOI: 10.12438/cst.2024-0239
|
In order to study the impact of bitumen filling on the mechanical characteristics of collapsible shaft lining joints, a combination of model testing and numerical calculations was employed. The study focused on the vertical plate retractable shaft wall joint located in the central air shaft of Linhuan Coal Mine of Huaibei Mining Group. The mechanical properties of the compressible wall joint model were tested under three different conditions: unfilled (Group K), filled with asphalt (Group T), and filled with asphalt with a blocked injection pipe (Group TD). Additionally, a fluid-structrue coupling finite element model was established for numerical simulation. The results indicate that, compared to the average ultimate bearing capacity of Group K, the average ultimate bearing capacity of Group T and Group TD increased by 12.81% and 21.51% respectively. The numerical calculation model was found to be feasible. The numerical analysis reveals that the vertical ultimate bearing capacity of Group T and Group TD is 11.04% and 25.84% higher than that of Group K, showing a consistent growth rate with the model test results. Further investigation demonstrates that as the vertical load gradually increases, the vertical stress on the inner and outer vertical plates of Group K increases linearly and eventually stabilizes. The vertical stress of the inner and outer vertical plates in group T did not increase steadily, but the slope of the vertical stress-vertical load curve of the vertical plates was smaller the closer they were to the asphalt overflow, and the slope of the vertical stress-vertical load curve at the same position was affected by the asphalt flow vortexes. Simultaneously, the higher the vertical load, the faster the asphalt flow speed, which makes the influence on the vertical bearing capacity of the shaft wall gradually increase. The increase in dynamic viscosity of asphalt results in a reduction of fluidity and wall shear force, thereby decreasing disturbance and pressure regulation on the vertical plate inside and outside the shaft wall.
| [1] |
刘志强,王飞,郭强. 深厚表土层井壁破裂机理及防治技术研究进展[J]. 煤炭科学技术,2011,39(4):6−10.
LIU Zhiqiang,WANG Fei,GUO Qiang. Research progress on mine shaft liner breaking mechanism and prevention technologies in deep and thick overburden[J]. Coal Science and Technology,2011,39(4):6−10.
|
| [2] |
薛维培,申磊,姚直书,等. 流固耦合状态下煤矿井壁破损透水机理研究[J]. 煤田地质与勘探,2023,51(10):86−93. doi: 10.12363/issn.1001-1986.22.10.0759
XUE Weipei,SHEN Lei,YAO Zhishu,et al. Water inrush mechanism of coal mine shaft fracture under fluid-solid coupling[J]. Coal Geology & Exploration,2023,51(10):86−93. doi: 10.12363/issn.1001-1986.22.10.0759
|
| [3] |
程桦,曹广勇,姚直书,等. 厚表土薄基岩特殊工程条件下的钻井井壁受拉破断机理[J]. 煤炭学报,2021,46(1):100−111.
CHENG Hua,CAO Guangyong,YAO Zhishu,et al. Tensile fracture mechanism of drilling shaft under the special engineering conditions of thick alluvium and thin bedrock[J]. Journal of China Coal Society,2021,46(1):100−111.
|
| [4] |
荣传新,程桦,姚直书. 钻井井壁可缩性接头力学特性研究[J]. 煤炭学报,2003,28(3):270−274.
RONG Chuanxin,CHENG Hua,YAO Zhishu. Study on compressive joint mechanics characteristic of shaft-boring lining[J]. Journal of China Coal Society,2003,28(3):270−274.
|
| [5] |
程桦,杨俊杰,姚直书,等. 钻井井壁可缩性接头模型试验研究[J]. 煤炭学报,2001,26(6):584−589.
CHENG Hua,YANG Junjie,YAO Zhishu,et al. Modeling experiments and studies on retractable flanging device for shaftwalls[J]. Journal of China Coal Society,2001,26(6):584−589.
|
| [6] |
荣传新,程桦,蔡海兵. 冻结井可缩性井壁接头力学特性研究及其应用[J]. 煤炭科学技术,2005,33(9):37−41,45. doi: 10.3969/j.issn.0253-2336.2005.09.013
RONG Chuanxin,CHENG Hua,CAI Haibing. Research and application on mechanics features of mine shaft lining shrinkable connector for freezing mine shaft[J]. Coal Science and Technology,2005,33(9):37−41,45. doi: 10.3969/j.issn.0253-2336.2005.09.013
|
| [7] |
张浩. 许疃煤矿改扩建工程冻结井可缩性井壁接头的研究与应用[D]. 淮南:安徽理工大学,2015.
ZHANG Hao. Research and application of compressible shaft lining joint in frozen shaft at reconstruction project of xutuan mine[D]. Huainan:Anhui University of Science & Technology,2015.
|
| [8] |
蔡海兵,程桦,姚直书,等. 深冻结井筒竖向可缩井壁的设计与施工技术[J]. 煤炭工程,2008,40(7):5−7. doi: 10.3969/j.issn.1671-0959.2008.07.001
CAI Haibing,CHENG Hua,YAO Zhishu,et al. Design and construction technology of vertical retractable shaft lining in deep freezing shaft[J]. Coal Engineering,2008,40(7):5−7. doi: 10.3969/j.issn.1671-0959.2008.07.001
|
| [9] |
舒恩,蔡海兵,张鑫,等. 三立板可缩性井壁接头优化设计分析[J]. 煤炭技术,2020,39(8):4−7.
SHU En,CAI Haibing,ZHANG Xin,et al. Optimum design and analysis of three vertical plate shrinkable wellbore joints[J]. Coal Technology,2020,39(8):4−7.
|
| [10] |
王涛,张鑫,舒恩. 双立板可缩性井壁接头优化设计分析[J]. 低温建筑技术,2020,42(2):59−61.
WANG Tao,ZHANG Xin,SHU En. Optimization design and analysis of the joint of the shaft wall with two vertical plates[J]. Low Temperature Architecture Technology,2020,42(2):59−61.
|
| [11] |
姚直书,程桦,杨俊杰. 地层沉降条件下可缩性钻井井壁受力机理的试验研究[J]. 岩土工程学报,2002,24(6):733−736. doi: 10.3321/j.issn:1000-4548.2002.06.013
YAO Zhishu,CHENG Hua,YANG Junjie. Experimental study on mechanical mechanism of retractable drilling shaft lining under the condition of stratum subsidence[J]. Chinese Journal of Geotechnical Engineering,2002,24(6):733−736. doi: 10.3321/j.issn:1000-4548.2002.06.013
|
| [12] |
薛大伟,张瀚文,程龙艺,等. 深冻结井内层可缩性井壁接头设计研究[J]. 山西建筑,2022,48(11):38−41.
XUE Dawei,ZHANG Hanwen,CHENG Longyi,et al. Study on the design of retractable well shaft lining joints of the deep freezing well inner layer[J]. Shanxi Architecture,2022,48(11):38−41.
|
| [13] |
ZHU X H,LIU W J,LIU Q Y. The mechanism and law of wellbore instability due to drill string impact in air drilling[J]. International Journal of Oil,Gas and Coal Technology,2014,8(2):153. doi: 10.1504/IJOGCT.2014.064843
|
| [14] |
裴庆夏,姚直书,张永坤. 信湖煤矿钻井井筒可缩性井壁接头设计及数值模拟研究[J]. 煤炭工程,2012,44(3):9−11. doi: 10.3969/j.issn.1671-0959.2012.03.005
PEI Qingxia,YAO Zhishu,ZHANG Yongkun. Design and numerical simulation of contractible shaft lining joint in xinhu coal mine[J]. Coal Engineering,2012,44(3):9−11. doi: 10.3969/j.issn.1671-0959.2012.03.005
|
| [15] |
崔广心,杨维好,柯昌松. 厚表土层中竖井沥青夹层复合井壁的试验研究[J]. 中国矿业大学学报,1995,24(4):11−17.
CUI Guangxin,YANG Weihao,KE Changsong. Study of the composite shaft lining with an asphalt filling in thick alluvium[J]. Journal of China University of Mining & Technology,1995,24(4):11−17.
|
| [16] |
赵坤. 沥青块滑动层与可缩板复合井壁的应用[J]. 煤炭科学技术,2000,28(1):12−13. doi: 10.3969/j.issn.0253-2336.2000.01.004
ZHAO Kun. Application of composite shaft lining of asphalt block sliding layer and retractable plate[J]. Coal Science and Technology,2000,28(1):12−13. doi: 10.3969/j.issn.0253-2336.2000.01.004
|
| [17] |
蔡海兵,李晓芳,程桦,等. 深井马头门处沥青块钢骨混凝土井壁结构的研究与应用[J]. 采矿与安全工程学报,2018,35(1):27−33.
CAI Haibing,LI Xiaofang,CHENG Hua,et al. Research on the structure of shaft lining with asphalt block and steel-reinforced concrete at deep shaft ingate and its application[J]. Journal of Mining & Safety Engineering,2018,35(1):27−33.
|
