MA Daibing，CHEN Lichao. Hydraulic fracturing effect of CBM vertical well and its impact on productivity: a case study of Yaojie Mining Area[J]. Coal Science and Technology，2023，51（6）：130−136
. DOI: 10.13199/j.cnki.cst.2022-0539| Citation: |
MA Daibing，CHEN Lichao. Hydraulic fracturing effect of CBM vertical well and its impact on productivity: a case study of Yaojie Mining Area[J]. Coal Science and Technology，2023，51（6）：130−136 . DOI: 10.13199/j.cnki.cst.2022-0539
|
CBM reservoir is a typical fracture-controlled gas reservoir, and the scale of fracturing and fracture-filling effect have decisive control on gas well productivity. In order to reveal the influence mechanism of the hydraulic fracturing effect of CBM vertical wells on the productivity effect of gas wells, taking the Haishiwan Mining Area of Yaojie, Gansu as an example, this paper focuses on reporting the fracturing effect of coal reservoirs under the form of vertical well development and its understanding of the constraints on productivity. the result shows: ① The fracture pressure of CBM well mainly feeds back the characteristics of the wellbore cement sheath rather than the mechanical properties of the coal reservoir. From the fracturing curve of this well, the fracture pressure is not obvious, indicating that the thickness of the cement sheath in the wellbore annulus is moderate, and the cement sheath is relatively easy to rupture during hydraulic fracturing. The energy of the injected fracturing fluid is mainly used to prop up the coal cracks; ② It can be seen from the fracturing curve that the propagation pressure of the hydraulic fractures(HF) in this well is relatively high, indicating that the structure of coal reservoir is relatively fragmented and coal fines are developed. In addition, there are multiple wave morphological features in the fracture propagation stage of the fracturing curve, indicating that multiple secondary fractures are propped up. On the whole, the HF in this well are relatively complex, and it is speculated that branched secondary fractures develop on both sides of the main HF. ③ Serious sand plugging occurred after sand injection in this well. The main reason was that the fracturing fluid in the coal reservoir was lost due to the loss of the fracturing fluid in the near-wellbore area, resulting in the formation of wedges by proppant de-sanding in the HF, which made subsequent proppant injection difficult. It is related to the coal fines of primary fractures and the development of a small amount of tectonic coal fines; ④ The fracturing microseismic monitoring data show that the main HF of the coal reservoir in this well are NE 50°, and the coal rock microseismic events are more active in the northeast direction, indicating that the natural fracture (NF) of the coal reservoir is more developed in this direction; Based on the observation results of fracturing and mineback, this paper proposes a division plan for the effective propped area, the actual fracture area and the rock mass disturbance area of HF. It is believed that the actual half-length of the HF in the coal reservoir of this well is less than 20 m, the half-length of the effectively propped HF is less than 5 m, and The small amount of fracturing fluid injected, the formation of wedges by proppant de-sanding induced by fracturing fluid-loss, and the sand plugging caused by coal fines accumulation are the main factors for the short fractures in the coal reservoir of this well; ⑤ Combined with the law of coalbed methane productivity, it is considered that the gas reservoir management and drainage system in this well is reasonable,However, the effective propped HF in the coal reservoir are too short, and the coal fines migration in the coal reservoir leads to the rapid decline of the conductivity of the near-well HF, which is the key restricting mechanism for the productivity of gas wells.It is recommended to increase the injection volume of fracturing fluid, appropriately increase the flow rate of fracturing fluid, reduce the proppant-sand ratio, and focus on controlling fracturing fluid leak-off and the formation of screenout wedges in the hydraulic fracturing of coal reservoirs in the later stage.The coal seam in this area has a large burial depth and high stress, and the realization of large-scale fracture propped is the key to coal reservoir fracturing. Meanwhile, the reservoir is dry and the fracturing fluid is seriously leak-off, the CO2 pre-fracturing test can be carried out.
| [1] |
袁士义, 宋新民, 冉启全. 裂缝性油藏开发技术[M]. 北京: 石油工业出版社, 2004.
YUAN Shiyi, SONG Xinmin, RAN Qiquan. Development technology of fractured reservoirs [M]. Beijing: Petroleum Industry Press, 2004.
|
| [2] |
孙海涛,舒龙勇,姜在炳,等. 煤矿区煤层气与煤炭协调开发机制模式及发展趋势[J]. 煤炭科学技术,2022,50(12):1−13.
SUN Haitao,SHU Longyong,JIANG Zaibing,et al. Progress and trend of key technologies of CBM developmentand utilization in China coal mine areas[J]. Coal Science and Technology,2022,50(12):1−13.
|
| [3] |
雷 群,管保山,才 博,等. 储集层改造技术进展及发展方向[J]. 石油勘探与开发,2019,46(3):580−587.
LEI Qun,GUAN Baoshan,CAI Bo,et al. Technological progress and prospects of reservoir stimulation[J]. Petroleum Exploration and Development,2019,46(3):580−587.
|
| [4] |
王生维, 陈立超. 煤储层水力压裂裂缝延展机制[M]. 武汉: 中国地质大学出版社, 2017.
WANG Shengwei, CHEN Lichao. Fracture propagation mechanism of hydraulic fracturing in coal reservoirs [M]. Wuhan: China University of Geosciences Press, 2017.
|
| [5] |
程远方,吴百烈,袁 征,等. 煤层气井水力压裂“T”型缝延伸模型的建立及应用[J]. 煤炭学报,2013,38(8):1430−1434.
CHENG Yuanfang,WU Bailie,YUAN Zheng,et al. Establishment and application of“T”shape fracture propagation model in hydraulic fracturing of methane well[J]. Journal of China Coal Society,2013,38(8):1430−1434.
|
| [6] |
傅雪海,许行行,王 强,等. 煤层气异常成分的界定、分布及其成因研究进展[J]. 煤炭科学技术,2023,51(1):343−352.
FU Xuehai,XU Hanghang,WANG Qiang,et al. Review of research on definition, distribution and causes of abnormal coalbed methane composition[J]. Coal Science and Technology,2023,51(1):343−352.
|
| [7] |
黄浩勇,韩忠英,王光磊,等. 压裂中顶底板对缝高控制作用的数值模拟研究[J]. 科学技术与工程,2015,15(6):181−184,209.
HUANG Haoyong,HAN Zhongying,WANG Guanglei,et al. Numerical simulation on the effect of crack height of roof and floor rock in fracturing[J]. Science Technology and Engineering,2015,15(6):181−184,209.
|
| [8] |
高向东,孙 昊,王延斌,等. 临兴地区深部煤储层地应力场及其对压裂缝形态的控制[J]. 煤炭科学技术,2022,50(8):140−150.
GAO Xiangdong,SUN Hao,WANG Yanbin,et al. In-situ stress field of deep coal reservoir in Linxing Area and its control on fracturing crack[J]. Coal Science and Technology,2022,50(8):140−150.
|
| [9] |
程远方,吴百烈,李 娜,等. 煤层压裂裂缝延伸及影响因素分析[J]. 特种油气藏,2013,20(2):126−129,157.
CHENG Yuanfang,WU Bailie,LI Na,et al. Analysis of hydraulic fracture extension and influencing factors in coal seam[J]. Special Oil and Gas Reservoirs,2013,20(2):126−129,157.
|
| [10] |
蒋廷学,卞晓冰. 深层油气藏多级迂回暂堵压裂技术研究[J]. 深圳大学学报(理工版),2021,38(6):590−597. doi: 10.3724/SP.J.1249.2021.06590
JIANG Tingxue,BIAN Xiaobing. Multistage circuitous-temporary plugging fracturing technology for deep oil-gas reservoirs[J]. Journal of Shenzhen University(Science and Engineering),2021,38(6):590−597. doi: 10.3724/SP.J.1249.2021.06590
|
| [11] |
郑新权,王 欣,张福祥,等. 国内石英砂支撑剂评价及砂源本地化研究进展与前景展望[J]. 中国石油勘探,2021,26(1):131−137.
ZHENG Xinquan,WANG Xin,ZHANG Fuxiang,et al. Domestic sand proppant evaluation and research progress of sand source localization and its prospects[J]. China Petroleum Exploration,2021,26(1):131−137.
|
| [12] |
吕明锟,曲占庆,郭天魁,等. 通道压裂支撑剂团块形成过程及影响因素[J]. 西安石油大学学报(自然科学版),2021,36(2):63−69.
LYU Mingkun,QU Zhanqing,GUO Tiankui,et al. Formation process and influence factors of proppant agglomerates in channel fracturing[J]. Journal of Xi’an Shiyou University( Natural Science Edition),2021,36(2):63−69.
|
| [13] |
陈立超,王生维,何俊铧,等. 煤粉源集合体对水力压裂效果的影响[J]. 中国矿业大学学报,2015,44(3):526−531.
CHEN Lichao,WANG Shengwei,HE Junhua,et al. Study of the impact of coal fines source collection on hydraulic fracturing effect[J]. Journal of China University of Mining and Technology,2015,44(3):526−531.
|
| [14] |
李 瑞,王生维,陈立超,等. 煤层气排采中煤粉产出量动态变化及影响因素[J]. 煤炭科学技术,2014,42(6):122−125.
LI Rui,WANG Shengwei,CHEN Lichao,et al. Coal powder output dynamic variation and influence factors during coalbed methane drainage[J]. Coal Science and Technology,2014,42(6):122−125.
|
| [15] |
ZHANG Lufeng,ZHOU Fujian,ZHANG Shicheng,et al. Evaluation of permeability damage caused by drilling and fracturing fluids in tight low permeability sandstone reservoirs[J]. Journal of Petroleum Science and Engineering,2019,175:1122−1135. doi: 10.1016/j.petrol.2019.01.031
|
| [16] |
陈立超,王生维,张典坤. 煤层气近井煤缝壁面滤饼的结构与硬度特征及工程意义[J]. 天然气工业,2020,40(6):100−106.
CHEN Lichao,WANG Shengwei,ZHANG Diankun. Structure and hardness characteristics of the filter cake-coal wall interface near a CBM well and its engineering significance[J]. Natural Gas Industry,2020,40(6):100−106.
|
| [17] |
王 飞,张士诚. 致密气储层清水压裂液侵入带动态分布及其对产能的影响规律[J]. 中国海上油气,2015,27(5):93−97.
WANG Fei,ZHANG Shicheng. Dynamic distribution of invaded zones by slick-water and its impacts on production performance in tight gas reservoirs[J]. China Offshore Oil & Gas,2015,27(5):93−97.
|
| [18] |
郭天魁,战永平,朱 丹,等. 多功能大尺寸真三轴储层改造实验装置的开发与应用[J]. 实验技术与管理,2021,38(2):108−115.
GUO Tiankui,ZHAN Yongping,ZHU Dan,et al. Development and application of multi-functional and large-scale true triaxial reservoir reconstruction experimental device[J]. Experimental Technology and Management,2021,38(2):108−115.
|
| [19] |
蒋廷学,卞晓冰,侯 磊,等. 粗糙裂缝内支撑剂运移铺置行为试验[J]. 中国石油大学学报(自然科学版),2021,45(6):95−101.
JIANG Tingxue,BIAN Xiaobing,HOU Lei,et al. Experiment on proppant migration and placement behavior in rough fractures[J]. Journal of China University of Petroleum(Natural Science Edition),2021,45(6):95−101.
|
| [20] |
吴峙颖,路保平,胡亚斐,等. 压裂多级裂缝内动态输砂物理模拟实验研究[J]. 石油钻探技术,2020,48(4):106−110.
WU Zhiying,LU Baoping,HU Yafei,et al. Experimental study on the physical simulation of dynamic sand transport in multi-stage fractures[J]. Petroleum Drilling Techniques,2020,48(4):106−110.
|
| [21] |
邹雨时,石善志,张士诚,等. 致密砾岩加砂压裂与裂缝导流能力实验:以准噶尔盆地玛湖致密砾岩为例[J]. 石油勘探与开发,2021,48(6):1202−1209.
ZOU Yushi,SHI Shanzhi,ZHANG Shicheng,et al. Experimental modeling of sanding fracturing and conductivity of propped fractures in conglomerate: a case study of tight conglomerate of Mahu sag in Junggar Basin, NW China[J]. Petroleum Exploration and Development,2021,48(6):1202−1209.
|
| [22] |
张士诚,李四海,邹雨时,等. 页岩油水平井多段压裂裂缝高度扩展试验[J]. 中国石油大学学报(自然科学版),2021,45(1):77−86.
ZHANG Shicheng,LI Sihai,ZOU Yushi,et al. Experimental study on fracture height propagation during multi-stage fracturing of horizontal wells in shale oil reservoirs[J]. Journal of China University of Petroleum(Natural Science Edition),2021,45(1):77−86.
|
| [23] |
陈立超,王生维,张典坤,等. 固井水泥浆侵入对煤储层压裂裂缝延展的影响[J]. 天然气工业,2019,39(8):74−81.
CHEN Lichao,WANG Shengwei,ZHANG Diankun,et al. Impact of cement slurry invasion on the propagation of hydraulic fractures in coal reservoirs[J]. Natural Gas Industry,2019,39(8):74−81.
|
| [24] |
陈立超,王生维,何俊铧,等. 煤层气井近井压裂裂缝充填特征与堵塞机制[J]. 中国石油大学学报(自然科学版),2017,41(6):117−122.
CHEN Lichao,WANG Shengwei,HE Junhua,et al. Filling characteristics and plugging mechanisms of hydraulic fractures near CBM vertical wells[J]. Journal of China University of Petroleum(Natural Science Edition),2017,41(6):117−122.
|
| [25] |
陈立超,王生维. 煤岩断裂力学性质对储层压裂改造的影响[J]. 天然气地球科学,2020,31(1):122−131.
CHEN Lichao,WANG Shengwei. Fracture properties of high-rank coal and its constraint on hydraulic fracturing stimulation of coalreservoir[J]. Natural Gas Geoscience,2020,31(1):122−131.
|
| [26] |
陈立超,王生维. 煤岩弹性力学性质与煤层破裂压力关系[J]. 天然气地球科学,2019,30(4):503−511. doi: 10.11764/j.issn.1672-1926.2018.12.004
CHEN Lichao,WANG Shengwei. Relationship between elastic mechanical properties and dequivalent fracture press of coal reservoir near wellbore[J]. Natural Gas Geoscience,2019,30(4):503−511. doi: 10.11764/j.issn.1672-1926.2018.12.004
|
| [27] |
陈立超,王生维,何俊铧,等. 煤层气藏非均质性及其对气井产能的控制[J]. 中国矿业大学学报,2016,45(1):105−110.
CHEN Lichao,WANG Shengwei,HE Junhua,et al. CBM reservoir heterogeneity and its controlling effect on gas well productivity[J]. Journal of China University of Mining and Technology,2016,45(1):105−110.
|
| [28] |
陈立超,王生维,张典坤,等. 基于渗水试验的煤岩压裂液静态滤失特征分析[J]. 中国煤炭,2020,46(6):90−97. doi: 10.3969/j.issn.1006-530X.2020.06.019
CHEN Lichao,WANG Shengwei,ZHANG Diankun,et al. Analysis of static leak-off characteristics of fracturing fluid through coal rocks based on water seepage tests[J]. China Coal,2020,46(6):90−97. doi: 10.3969/j.issn.1006-530X.2020.06.019
|
